Unokukhetha njani, ukuFaka, kunye nokugcina iiMoto zeRotary Orbital Hydraulic kuBomi obuphezulu beNkonzo?

Esi sikhokelo sinqumla ithiyori ukunikezela ngemibono enokuthatha amanyathelo-ukusuka kubungakanani bemoto efanelekileyo kwisicelo sakho, ukuya kubuchule bokufakela obufanelekileyo, ukuya kwiindlela zogcino lwemihla ngemihla okwandisa ubomi benkonzo.

1. UMGaqo wokuSebenzisa onguNdoqo-Yintoni eyenza ukuba uhambise iTorque ephezulu?

Intliziyo yeimoto ye-orbitalyisethi yangaphakathi ye-meshing gear - i-rotor (i-outer gear) kunye ne-stator (i-internal gear) - kunye nomgaqo woyilo olubalulekileyo lokuba i-rotor inezinyo elinye elingaphantsi kwe-stator. Xa i-pressurized hydraulic fluid ingena kwi-motor, inyanzelisa i-rotor ukuba yenze intshukumo ye-orbital (iplanethi) ngaphakathi kwe-stator. Esi ntshukumo sihanjiswa ngeshafu yokudibanisa yangaphakathi ukuya kwi-shaft yokuphuma, ukuguqula intshukumo ye-orbital ibe yimveliso ejikelezayo egudileyo.

Olu luyilo luzisa eyona nto ibalulekileyo: Isantya esisezantsi-Torque (LSHT) . Ngokungafaniyo ne-vane okanye ii-piston motors, iimoto ze-orbital zinokuvelisa i-torque eyomeleleyo, ezinzileyo ngokuthe ngqo kwi-RPM ephantsi ngaphandle kokufuna isinciphisi segiya. Oku kubaluleke kakhulu kwizicelo ezifuna ulawulo lwesantya esichanekileyo kunye netorque ephezulu phantsi kwemithwalo enzima.

Ulungelelwaniso oluphambili lwestator lukhona:

• I-Gerotor (i-stator-piece-piece): I-stator yiringi enye yangaphakathi yegiya. Uqoqosho kunye nokuthembeka kumjikelo ophakathi.

• I-Geroler (i-stator exhotywe nge-roller): I-Roller okanye iinaliti zifakwe kumazinyo e-stator, ukuguqula i-sliding friction ibe yi-rolling friction. Oku kuvelisa ukusebenza kakuhle okuphezulu, ukumelana nomthwalo womothuko, kunye nokuphila ixesha elide lokunxiba-ilungele umsebenzi onzima, imisebenzi ephezulu.

2. Ubungakanani obusebenzayo-Ukukhetha "Intliziyo" eLungileyo kumatshini wakho

Ubungakanani benjini obungachanekanga ngunobangela #1 wokusilela kwangaphambi kwexesha. Ukuthoba ngaphantsi kukhokelela kumonakalo ogqithisileyo; ukugqithisa inkunkuma yeendleko kunye nokunciphisa ukusebenza kakuhle kwenkqubo iyonke. Gxininisa kwezi parameters zibalulekileyo:

• ITorque, Isantya kunye noKufuduswa (Unxantathu) : Ukushenxiswa (cc/rev) kuqinisekisa ngokuthe ngqo imveliso yetorque – ukufuduswa okukhulu kuthetha ulwelo oluninzi nge revolution, kungoko itorque ephezulu, kodwa isantya esiphezulu sisezantsi. Soloko uchaza itorque yokuqalisa (eqhele ukuba phezulu kunetorque ebalekayo) kunye noluhlu lwesantya esisebenzayo phambi kokukhetha ukususwa. Qwalasela ngegophe lokusebenza lomenzi - ungaze ukhethe injini esebenza kwimida yayo egqithileyo; jolise kwincopho-yokusebenza zone yoxinzelelo lwenkqubo/iprofayile yakho yokuhamba.

• Uxinzelelo lweSistim kunye nenqanaba lokuHamba: Qinisekisa iyunithi yakho amandla oxinzelelo oluqhubekayo lokusebenza kunye nobona buninzi bokuqukuqela obukhoyo. Uxinzelelo lunciphisa i-torque ephezulu, ngelixa ukuhamba kugqiba isantya esiphezulu esifikelelekayo. Thelekisa oku ngokuchasene nenkcazelo ekalijiweyo yemoto. Qinisekisa ukuba owona mlinganiselo uphezulu woxinzelelo lwemoto unomda wokhuseleko ofanelekileyo ngaphezulu kwencopho yesixokelelwano sakho spikes (sebenzisa ivalve yokukhulula uxinzelelo ngokufanelekileyo).

• UkuNyusa kunye nokuLayishwa kweShaft: Ngaphaya kweepateni zebholiti kunye nobukhulu beflange, umthamo womthwalo weradial kwi-shaft ephumayo uhlala ungahoywa. Ukuba ufaka i-sprocket, i-pulley, okanye ibhanti yokuqhuba ngokuthe ngqo kwi-shaft, imithwalo yecala ebalulekileyo iyaziswa. Kwiimeko ezinjalo, kufuneka ukhethe i-motor eneebheringi zobunzima obunzima kwaye ujonge itshathi yokukala umthwalo weradial yomenzi. Ukungahoyi oku kukhokelela ekungaphumelelini kokuthwala ngokukhawuleza kunye nokuvuza kwetywina.

• Imo engqongileyo kunye neeMfuno eziKhethekileyo: Kumaqondo obushushu agqithisileyo, iimeko ezinothuli, okanye iindawo zokufuma okuphezulu, khankanya amatywina aphuculweyo (umzekelo, iViton okanye i-HNBR) kunye nezinto ezikwaziyo ukutyiwa. Kusetyenziso olufuna i-dynamic braking okanye imval yesantya, qwalasela iinketho ezidityanisiweyo ezifana neevalvu zebrake, iitachometers, okanye iivalvu zolawulo olulungelelanisiweyo.

3. Ukufakela kunye nokuThunyelwa - Iinkcukacha Ezenza okanye Ezaphule Ukusebenza

Imoto ekhethwe ngokugqibeleleyo inokusilela ngokukhawuleza ukuba ifakwe ngokungalunganga. Landela la manyathelo angaxoxisiyo:

1. Ulungelelwaniso lweShaft oluchanekileyo: Ulungelelwaniso lwe-coaxial ngokupheleleyo phakathi kweshafti yemoto kunye nomthwalo oqhutywayo kuyanyanzeleka. Nakuphi na ulungelelwaniso olungalunganga lwe-angular okanye olunxuseneyo luzisa i-radial okanye i-axial forces enciphisa kakhulu ubomi bokuzala. Sebenzisa isalathisi sokudayela okanye isixhobo sokulungelelanisa i-laser kwaye unamathele ngokungqongqo kukunyamezela komenzi (ngokuqhelekileyo ≤ 0.05 mm i-radial runout).

2. UQhagamshelo lweZibuko oluLungileyo: Jonga kabini ukuchongwa kwesibuko – Uxinzelelo (P), uBuyisela (T), kunye neDrain (L) . I-drain port ibalulekile: kufuneka ifakwe umbhobho ngokwahlukileyo emva kwetanki kunye noxinzelelo oluncinci lwasemva (ngokuqhelekileyo <5-10 bar, jongana ne-specs). Ungaze uplage i-drain port-ukwenza oko kuya kuvuthela i-shaft seal ngoko nangoko.

3. Ukugungxulwa kweSistim Phambi KokuQalisa: Phambi kokudibanisa i-motor, gubha yonke inkqubo yoxinzelelo lwe-hydraulic (imibhobho, iivalvu, ii-coolers) ngolwelo olucocekileyo ukususa i-welding slag, ukungcola, okanye inkunkuma eshiywe kufakelo. Ungcoliseko oluvezwe ngexesha lokuseta ngunobangela ophambili wokunxitywa kwangoko.

4. Inkqubo yokuQala yokuQalwa: Kwiimoto ezintsha okanye ezakhiwe ngokutsha, sebenzisa iyunithi ngama-30–50% omthwalo okaliwe malunga nemizuzu engama-30–60 phambi kokuba usebenze ngomthwalo ogcweleyo. Oku kuvumela iigiya zangaphakathi kunye neebheringi ukuba zihlangane ngokufanelekileyo kwaye zizinzise ukucocwa kwangaphakathi, ukwandisa kakhulu ukuqina kwexesha elide.

4. ULondolozo lweMihla yonke kunye noFundo lweFault eKhawulezayo

Khumbula umgaqo wegolide: 90% yokusilela kweenjini zolwelo olwenziwa ngamanzi abuyela emva kungcoliseko okanye ubushushu obungafanelekanga bolwelo. Ugcino alunyanzelekanga - lubomi besixhobo sakho.

Ulawulo lolwelo-Undoqo wakho we-#1:

• Ucoceko: Amasuntswana aqinileyo asebenza njengekhompawundi yokurhabula, enxibe iperi yerotor-stator eyenziwe ngoomatshini. Oku kwandisa ukuvuza kwangaphakathi, kwehlisa ukusebenza kwe-volumetric, kunye nokunciphisa i-torque. Jonga inqanaba lococeko le-ISO 4406 18/16/13 okanye elingcono, kwaye uhlole/utshintshe izihluzo zomgca wokubuyela rhoqo. Sebenzisa isalathisi soxinzelelo oluhlukileyo kwizindlu zokucoca.

• Viscosity & Temperature: Olona luhlu lwe-viscosity luphezulu yi-20–43 cSt ku-50°C. Gcina ubushushu be-oyile ngaphantsi kwe-60°C ngomsebenzi oqhubekayo; ungaze udlule kuma-85°C nakwiincopho. Amaqondo obushushu aphezulu anciphisa i-oyile, anciphisa ukuthambisa kunye nokukhawulezisa ukuthotywa kwetywina. Amaqondo obushushu aphantsi anyusa i-viscous drag, ebangela i-cavitation kunye ne-sluggish starts. Fakela igeyiji yobushushu kunye nepholile xa kukho imfuneko.

• Ungaze Uxube Iintlobo zolwelo: Ngokuqinisekileyo SUKU sebenzisa i-oyile ye-injini endaweni yolwelo oluqhutywa ngamanzi. Iiphakheji zabo ezongezelelweyo azihambelani. Ukuxuba kunokubangela ukudumba kwetywina, ukugwebu, ukuvanishi, kunye nokusilela okuyintlekele. Ngalo lonke ixesha sebenzisa ibakala le-OEM elicetyiswayo lolwelo olwenziwa ngamanzi.

Itheyibhile yoFundo oluKhawulezayo

Ukuhlolwa kweMpilo okucwangcisiweyo

Zidibanise ezi kwisicwangciso sakho sogcino lothintelo:

• Rhoqo ngeveki: Jonga iqondo lobushushu langaphandle (sebenzisa ithemometha ye-infrared) kwaye umamele ukunkqonkqoza okungaqhelekanga okanye ukuncwina.

• Ngenyanga: Hlola zonke izifakelo zemibhobho kunye nezitywina zokulila.

• Ngekota: Thatha isampuli yeoli kwaye uyithumele kuhlalutyo lwe-spectrometric - amanqanaba anyukayo entsimbi, ubhedu, okanye amasuntswana e-silicon zizibonakaliso zokuqala zokunxitywa kwangaphakathi ixesha elide ngaphambi kokuba ukusebenza kwehle ngokubonakalayo.

Ukujikelezai-i-orbital hydraulic motorlihashe elomeleleyo nelithembekileyo xa liphathwa ngokuchanekileyo. Impumelelo ilele kwiintsika ezintathu: ukuyilinganisa ngokuchanekileyo kwiprofayile yakho yomthwalo wehlabathi lokwenyani, ukuyifaka ngoqhaqho oluchanekileyo, kunye nokugcina impilo yolwelo njengento engaxoxisiyo. Xa uthandabuza, soloko ubhekisa kwiigophe zokusebenza ezikhethekileyo zomenzi kunye namathuba eenkonzo - kwaye ungalibazisi ukubandakanya iinjineli zabo zesicelo semijikelo enzima yomsebenzi okanye udibaniso lwesiqhelo.

Ukuba ufuna inkcazelo eyongezelelekileyo kuwo nawuphi na umba othile - onjengobalo oluneenkcukacha lomthwalo weradial, ukhetho oluhlanganisiweyo lwevalvu, okanye ukhetho lokutywina lobushushu obuphezulu - nceda undazise kwaye ndiyakwazi ukwandisa.
